Specifications
GMC24L
Distance between Columns
2000 mm
X-axis
3000 / 3500 / 4000 / 4500 mm
Y-axis (Processing space)
2400mm
Z-axis
850 mm
Travel
Distance from table surface to spindle gauge plane
200 - 1050 mm
255 - 1105 mm
Work Table Width
1800 mm
T-slot
22 mm
Work Table
Maximum Load
13 / 14 / 16 / 18 Tonne
Spindle Drive
Direct-Drive + Gear Reducer
Motorized Spindle
Spindle Taper
BT50
HSK63
Spindle Speed
8000 rpm
12 000 rpm
Spindle Motor Power (Continuous / Maximum)
22 / 26 kW
25 / 44 kW
Spindle Torque (Continuous / Maximum)
560/ 661 N.m
87 / 150 N.m
Spindle
Spindle Box Section
400 x 400 mm
Rapid Traverse X / Y / Z
16 / 16 / 16 m/min
Feed
Cutting Speed
12 m/min
Positioning X-axis
0.018 / 0.02 / 0.021 / 0.023 mm
Positioning Y-axis
0.016 mm
Positioning Z-axis
0.011 mm
Repeatability X-axis
0.011 / 0.013 / 0.014 / 0.015 mm
Repeatability Y-axis
0.01 mm
Accuracy (20 ± 0.5℃)
Repeatability Z-axis
0.006 mm
Power Capacity
60 kVA
Air Source
6.5 kg/cm²
Height (est.)
5100 mm
Floor Area (est.)
9000 / 10 250 / 11 250 / 12 250 x 5400 mm
Other
Nett Weight (est.)
32 / 35/ 38.5 / 42 Tonne
Control System
Fanuc / Siemens
Gantry CNC Milling Machine
Features
Standard Configuration • Spindle • Reduction gearbox • Spindle coupling • Roller linear guide • Chain-type chip conveyor • Hydraulic station • Oil cooler • Air filter • Spindle air blast • Air gun • Air conditioner • Work piece water cooling • Towing chain for three axes • Safety guard Optional Configuration • Column heightening • Water gun • Spindle spray • Coolant through spindle • Grating scale • Tool magazine • Accessory head • Tool measuring and testing machine • Probe head
